Ceiling Speaker
Premium‑sound Ceiling Loudspeaker 30W-LC2‑PC30G6‑8
- 8-inch coaxial two-way
- Waveguide coupled Ti tweeter
- Full bandwidth overload protection
- Front baffle wattage tap adjustment
- BS 5839-8 and EN 60849 compliant
Technical Specifications:
| Electrical | |
|---|
| Maximum power | 75 W |
| Rated power | 30 / 15 / 7.5 / 3.75 W (1.88 W only, 70 V). |
| Sound pressure level at 30 W / 1 W (1 kHz, 1 m) | 106 / 91 dB (SPL) |
| Effective frequency range (-10 dB) | 50 Hz to 20 kHz |
| Coverage (conical) | 110° |
| Rated voltage | 70 V or 100 V |
| Rated impedance | 167 or 333 or 8 ohm |
| LF transducer | 200 mm (8 in.) Polypropylene cone |
| HF transducer | 25 mm (1 in.) Ti Mylar laminate |
| Connector | 3‑pole ceramic screw terminal block |
| Mechanical | |
| Diameter | 300 mm (11.8 in) |
| Maximum depth | 255 mm (10 in) |
| Ceiling thickness | 4 to 25 mm (0.16 to 1.00 in.) |
| Mounting cut‑out | 272 + 5 mm (10.75 + 0.20 in.) |
| Material | |
| Baffle | ABS (UL94V0) |
| Back‑can | Zinc‑plated steel |
| Grille | Powder coated steel |
| Weight | 5 kg (11 lb) |
| Color | White (RAL 9010) |
| Environmental | |
| Operating temperature | -25 ºC to +55 ºC (-13 ºF to +131 ºF) |
| Storage temperature | -40 ºC to +70 ºC (-40 ºF to +158 ºF) |
| Relative humidity | <95% |
